2- Transponders :
The transponders communicate with the decoder by means of Radio signals.
They
are battery-powered (batteries integrated), so their mounting on the kart is quick
and
easy.
Their antenna is flexible, elastic and unbreakable; it can be completely folded without any risk.
An aluminium version very robust is also available
RC4 Karting
transponder
Aluminium version
Specifications :
|
Specifications |
RC4
Karting transponder | RC4 Karting aluminium transponder |
|
Number of codes available |
65000 | 65000 |
|
Response time |
< 2ms | < 2ms |
| Critical detection height
(simple magnet bar) |
11cm = 4.3" | 11cm = 4.3" |
| Critical detection height
(magnet bar doubled) |
15cm = 5.9" | 15cm = 5.9" |
|
Standby current consumption |
3µA | 3µA |
|
Operating current consumption |
33mA | 33mA |
| Battery autonomy, standby mode |
3 years | 3 years |
|
Battery autonomy, number of
laps |
200
000 laps | 200 000 laps |
| Battery type (replaceable) | 1 battery CR2450 | 1 battery CR2450 |
|
Temperature range |
-10°C / + 55°C | -10°C / + 55°C |
| Dimensions ( L x W x H ) | 75
x 50 x 18 mm | 69 x 49 x 35 mm |
| Weight (battery included) | 40g | 135g |
